Building Linux Packages for Kernel Drivers! (Dkms Howto)

Background

Most of the time the Linux kernel does a great job of having drivers you need, but sometimes you need to install a special driver or update an existing module.

Running make; make install is all fine and dandy for testing, but for production you want a repeatable process. For me, this means OS packages. (deb/rpms)

33657094

So, how do you go from kernel module source code => Debian package? DKMS. DKMS will automatically build your kernel module for you, even if your kernel gets updated.

Example: ixgbe

Lets build something. In this example I’m on an Ubuntu machine building the latest ixgbe driver.

  1. Get apt-get your stuff
1
    apt-get install debhelper dkms kernel-headers
  1. Untar your source code into /usr/src/$modulename-$version, like /usr/src/ixgbe-3.12.6/
  2. Normally here you would run “make”, but instead we will make a dkms.conf file to describe how to build it. Like this:
1
2
3
4
5
6
7
8
    MAKE="make -C src/ KERNELDIR=/lib/modules/${kernelver}/build"
    CLEAN="make -C src/ clean"
    BUILT_MODULE_NAME=ixgbe
    BUILT_MODULE_LOCATION=src/
    DEST_MODULE_LOCATION="/updates"
    PACKAGE_NAME=ixgbe-dkms
    PACKAGE_VERSION=3.12.6
    REMAKE_INITRD=no
  1. Next we need to register that module with dkms:
1
2
3
4
    root@server:/usr/src/ixgbe-3.12.6# dkms add -m ixgbe -v 3.12.6
    Creating symlink /var/lib/dkms/ixgbe/3.12.6/source ->
     /usr/src/ixgbe-3.12.6
    DKMS: add completed.
  1. Next we will build the module, but using the dkms build command instead of make:
1
2
3
4
5
6
7
    root@server:/usr/src/ixgbe-3.12.6# dkms build -m ixgbe -v 3.12.6
    Kernel preparation unnecessary for this kernel. Skipping...
    Building module:
    cleaning build area....
    make KERNELRELEASE=3.2.0-23-generic -C src/ KERNELDIR=/lib/modules/3.2.0-23-generic/build....................
    cleaning build area....
    DKMS: build completed.
  1. Great! Next we will make a debian src package.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
    root@server:/usr/src/ixgbe-3.12.6# dkms mkdsc -m ixgbe -v 3.12.6 --source-only
    Using /etc/dkms/template-dkms-mkdsc
    copying template...
    modifying debian/changelog...
    modifying debian/compat...
    modifying debian/control...
    modifying debian/copyright...
    modifying debian/dirs...
    modifying debian/postinst...
    modifying debian/prerm...
    modifying debian/README.Debian...
    modifying debian/rules...
    copying legacy postinstall template...
    Copying source tree...
    Building source package... dpkg-source --before-build ixgbe-dkms-3.12.6
     debian/rules clean
     dpkg-source -b ixgbe-dkms-3.12.6
    dpkg-source: warning: no source format specified in debian/source/format, see dpkg-source(1)
     dpkg-genchanges -S >../ixgbe-dkms_3.12.6_source.changes
    dpkg-genchanges: including full source code in upload
     dpkg-source --after-build ixgbe-dkms-3.12.6
    DKMS: mkdsc completed.
    Moving built files to /var/lib/dkms/ixgbe/3.12.6/dsc...
    Cleaning up temporary files...
  1. Now we will build the “binary” debian package. In reality with –source-only this binary package just contains the source code in the module with a post install script to build the module for each kernel you are using. Its magic:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
    root@server:/usr/src/ixgbe-3.12.6# dkms mkdeb -m ixgbe -v 3.12.6 --source-only
    Using /etc/dkms/template-dkms-mkdeb
    copying template...
    modifying debian/changelog...
    modifying debian/compat...
    modifying debian/control...
    modifying debian/copyright...
    modifying debian/dirs...
    modifying debian/postinst...
    modifying debian/prerm...
    modifying debian/README.Debian...
    modifying debian/rules...
    copying legacy postinstall template...
    Copying source tree...
    Building binary package...dpkg-buildpackage: warning: using a gain-root-command while being root
     dpkg-source --before-build ixgbe-dkms-3.12.6
     fakeroot debian/rules clean
     debian/rules build
     fakeroot debian/rules binary
     dpkg-genchanges -b >../ixgbe-dkms_3.12.6_amd64.changes
    dpkg-genchanges: binary-only upload - not including any source code
     dpkg-source --after-build ixgbe-dkms-3.12.6
    DKMS: mkdeb completed.
    Moving built files to /var/lib/dkms/ixgbe/3.12.6/deb...
    Cleaning up temporary files...
  1. We have a deb! Lets put it in ~
1
    root@server:/usr/src/ixgbe-3.12.6# cp /var/lib/dkms/ixgbe/3.12.6/deb/ixgbe-dkms_3.12.6_all.deb ~
  1. So we have a deb. I would like to install it, but we have to get rid of the build files so they will not conflict with the deb we just built:
1
    root@server:/usr/src/ixgbe-3.12.6# rm -r /var/lib/dkms/ixgbe/
  1. Now we have a deb that you can install locally, distribute wherever, install across a cluster:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
    root@server:/usr/src/ixgbe-3.12.6# dpkg -i /root/ixgbe-dkms_3.12.6_all.deb
    Selecting previously unselected package ixgbe-dkms.
    (Reading database ... 56500 files and directories currently installed.)
    Unpacking ixgbe-dkms (from .../root/ixgbe-dkms_3.12.6_all.deb) ...
    Setting up ixgbe-dkms (3.12.6) ...
    Loading new ixgbe-3.12.6 DKMS files...
    First Installation: checking all kernels...
    Building only for 3.2.0-23-generic
    Building for architecture x86_64
    Building initial module for 3.2.0-23-generic
    Done.
    ixgbe:
    Running module version sanity check.
    - Original module
    - Installation
    - Installing to /lib/modules/3.2.0-23-generic/updates/dkms/
    depmod....
    DKMS: install completed.

33657298
